Polyester Spiral Press-Filter Fabrics



Polyester Spiral Press-Filter Fabrics is add the filler wire into spiral ring, so the air permeability is reduced and less material loss on the surface of the fabric.
Mainly used in paper making, printing and dyeing, food, pharmaceutical, ceramics and solid-liquid separation industries like sludge dehydration.



Polyester Spiral Press-Filter Fabrics Polyester Spiral Press-Filter Fabrics
Spiral filter press cloth Spiral filter press cloth

Type of spiral dryer fabric

Model of fabric

Diameter (mm)

Air permeability m3/m3h

warp

weft

Large loop

LW 4.0*8.0

0.9

1.1

20000±500

Medium loop

LW 3.8*6.7

0.7

0.9

18500±500

Small loop

LW 3.2*5.2

0.52

0.7

15000± 500
